RISA-3D is expanding its industry leading support for the analysis and design of various materials with the implementation of Seismic Design of Masonry Wall Panels according to the provisions of TMS 402-16 (as well as ACI 530-13). When creating a model in RISA-3D, users now have the ability to...
When determining the Depth of Compression Block value of ‘a’ in a Masonry Wall design based on the equation a = (As * fy)/(0.8 * fm * b) in a RISA-3D model, it is possible to see a small variance in the program results versus a traditional hand calculation using this typical equation. The reason...
In RISA-3D, the current method of design for masonry lintels is Simply Supported where the masonry lintels are idealized into a simply supported pin-pin beam configuration. Now, masonry lintels can instead be analyzed using finite element analysis. With this method, the lintel will be fully...
In RISA-3D we now have the ability to:
The new TMS 402-16 Masonry Code (formerly designated as ACI 530 and ASCE 5) have been added to RISA-3D v16.0, RISAFloor v12.0 and RISAFoundation v10.0.
Now available in RISAFoundation v9 is the ability to design masonry retaining walls and strip footings with the latest US codes. Simply define your masonry wall and reinforcement parameters in the Wall Footing Definition Editor and then draw your wall footing.
